UAT 500VA ~1250VAUAT 500VA ~1250VAUAT 500VA ~1250VAUAT 500VA ~1250VA

Availability: In stock

Model number: UAT-500VA-1250VA

Inquiry
Quantity

Excellent Power Assurance "Off Line UPS" UAT 500VA ~1250VA

This kind of UPS is specially designed for computer system and accurate electronically-controlled devices with clean power output. The unit will switch to inverter mode in a very quick response time less than 8ms in the event of outage, sag, blackout to ensure the normal performance of load.


Feature :
  • An EMI filter for atmospheric disturbance suppression
  • maximum compactness
  • 3 sockets with mains fail protection
  • 1 socket without mains fail protection for powering loads such as laser printers
  • integrated protection for telephone line/modem
  • cold start capability: the UPS can power up without a mains supply present
  • user replaceable batteries
  • RS232 interface
  • can be placed on desktop, floor, or be wall-mounted
  • short-circuit protection
  • auto restart (on mains return, after batteries have discharged)
  • CE marks
Specifications:
ModelUAT-500VAUAT-650VAUAT-850VAUAT-1250VA
Input voltage140 ~ 280V for 220V , 85 ~ 135V for 110V
Output voltage190 ~ 250V for 220V, 95 ~ 125V for 110V
Switch time< 8ms
WaveformMain mode: sine wave; Battery mode: square wave
Protection typeOverload, short circuit, over-charging
Overload, short circuit and low battery voltageUPS shut down automatically
alarm and LED displayAlarm every 4-second if powered by battery with red lamp flashing; alarm every second upon depletion of battery with red lamp flashing
Battery typeMaintenance -free Sealed Lead acid Battery , Leakproof
Backup time1 x PC2 x PC
10 ~ 13 m8 ~ 12m
Batteries1x12V 7.2AH1 x 12V 9AH2 X 12V 7.2AH
Net weight6.57.511
Dimension ( packing size)410*180*230480 X225 X295
Efficiency>90%
Charging time> 8 hours (90%)
Price Termexw
Loading Quantity500Va/650va /800va1500pc/20'container  9.75MT
3200PCS/40' container 20.8MT
 1250va800PCS/20' container 8.8MT
1700PCS/40'container 18.7MT
